Improve warehouse transport, pallet stacking, loading, and industrial material handling with this 3.5-Ton Electric Counterbalance Forklift. Designed for seated operation, this heavy-duty electric forklift combines a 3,500 kg lifting capacity, lithium-ion battery system, two-stage mast, hydraulic side shifter, and solid industrial tyres for reliable commercial and industrial operation.

The fully electric drivetrain delivers quiet, efficient operation with no direct exhaust emissions during use, making the forklift suitable for warehouses, manufacturing facilities, distribution centres, loading bays, building-material facilities, and paved industrial yards.

Key Features

• 3,500 kg rated lifting capacity
• Fully electric counterbalance forklift
• Rechargeable lithium-ion battery
• 60V electrical system
• Seated operator configuration
• Two-stage lifting mast
• Lift height up to 3,500 mm
• Hydraulic side shifter
• Rear-wheel-drive configuration
• Solid industrial tyres
• 1,220 mm fork length
• Multiple fork-width options
• 1,700 mm wheelbase
• 2,400 mm turning radius
• 14 km/h unloaded travel speed
• Custom fork configurations available
• Custom body colour and equipment options
• Suitable for indoor and paved outdoor operations

Product Specifications

• Product Type: Electric Counterbalance Forklift
• Condition: New
• Operating Mode: Seated Operation
• Rated Lifting Capacity: 3,500 kg
• Power Source: Rechargeable Electric Battery
• Battery Type: Lithium-Ion
• Electrical System: 60V
• Charging Time: 4–6 Hours
• Drive Type: Rear-Wheel Drive
• Mast Type: Two-Stage Mast
• Maximum Lift Height: 3,500 mm
• Fork Length: 1,220 mm
• Fork Width Options: 100 mm / 125 mm
• Side Shifter: Hydraulic
• Tyre Type: Solid Industrial Tyres
• Wheelbase: 1,700 mm
• Turning Radius: 2,400 mm
• Unloaded Travel Speed: 14 km/h
• Terrain Suitability: Indoor Industrial Floors and Paved Outdoor Surfaces
• Colour: Customizable

3,500 kg Lifting Capacity

The forklift provides a 3.5-ton rated lifting capacity, making it suitable for handling heavier pallets, machinery components, building materials, packaged goods, manufacturing supplies, and other industrial loads.

Its counterbalance configuration provides the stability required for regular lifting, transporting, loading, and stacking operations.

Lithium-Ion Battery System

The 60V lithium-ion electrical system provides rechargeable electric power for warehouse and industrial operations.

Lithium battery technology provides practical advantages including:

• Rechargeable electric operation
• Quiet drivetrain performance
• No direct exhaust emissions during use
• Reduced engine-related maintenance
• Consistent electric power delivery
• Convenient operation in indoor industrial environments

The charging time is 4–6 hours using the compatible charging system.

Two-Stage Mast

The two-stage mast provides a lifting height of up to 3,500 mm, supporting pallet stacking, truck loading, warehouse storage, production-line supply, and general industrial lifting.

The mast configuration provides controlled vertical movement while maintaining visibility around the load-handling area.

Hydraulic Side Shifter

The integrated hydraulic side shifter allows the operator to move the forks horizontally without repeatedly repositioning the forklift.

This provides greater control during:

• Pallet alignment
• Warehouse rack placement
• Truck loading and unloading
• Container loading
• Production-line supply
• Tight positioning operations

The side shifter is particularly useful when precise pallet positioning is required.

Fork Configuration

The forklift is equipped with 1,220 mm forks for industrial pallet and material handling.

Available fork widths include:

• 100 mm
• 125 mm

Custom fork dimensions can also be configured for different load-handling requirements.

Solid Industrial Tyres

Solid industrial tyres provide durable and puncture-resistant performance for regular warehouse and commercial use.

They are suitable for:

• Warehouse flooring
• Factory floors
• Loading bays
• Distribution facilities
• Smooth concrete surfaces
• Paved industrial yards
• Building-material facilities

Their solid construction eliminates conventional pneumatic punctures and helps reduce routine tyre maintenance.

Travel and Manoeuvrability

The forklift combines a 1,700 mm wheelbase with a 2,400 mm turning radius, providing controlled manoeuvrability for industrial material-handling operations.

The unloaded travel speed reaches 14 km/h, supporting efficient movement between loading, storage, and production areas.

Suitable Applications

This 3.5-Ton Electric Counterbalance Forklift is suitable for:

• Warehouses
• Manufacturing plants
• Distribution centres
• Building-material facilities
• Retail distribution
• Loading bays
• Industrial storage facilities
• Farms and agricultural storage
• Food and beverage facilities
• Production facilities
• Construction-material handling
• Indoor logistics operations
• Paved industrial yards

Customization Options

Available configurations include:

• Battery capacity
• Charger configuration
• Lift height
• Fork dimensions
• Tyre configuration
• Hydraulic attachments
• Operator cabin
• Weather cover
• Mirrors
• LED work lights
• Warning beacon
• Reversing alarm
• Control panel
• Body colour
• Company logo

Safety Information

Only trained and authorized personnel should operate the forklift. Never exceed the rated lifting capacity stated on the machine capacity plate.

Keep loads lowered while travelling and avoid sudden turns, unstable surfaces, excessive slopes, and unsuitable terrain. Inspect the forks, mast, lift chains, hydraulic system, battery, tyres, steering, brakes, side shifter, lights, and warning equipment before operation.
