Improve pallet movement, warehouse stacking, workshop transport, and compact material handling with this 0.8-Ton Three-Wheel Electric Forklift. Designed for light-duty operations and confined working areas, this compact forklift combines an 800 kg lifting capacity, 2,000 mm lift height, 1,500W brushless AC travel motor, and 48V 52Ah battery system.

The three-wheel support configuration provides a compact footprint for manoeuvring in warehouses, workshops, retail stockrooms, small factories, and indoor logistics facilities.

Key Features

• 800 kg rated lifting capacity
• 2,000 mm maximum lifting height
• Compact three-wheel design
• 1,500W brushless AC travel motor
• 48V 52Ah battery system
• Dry battery configuration
• 4–6 hours working time
• 6–8 hours charging time
• Mechanical steering system
• Battery-level display
• Thickened one-piece steel body
• 12° maximum listed gradeability
• Compact 900 mm overall width
• 850 kg machine weight
• Suitable for narrow indoor working areas
• Custom colour options

Product Specifications

• Product Type: Three-Wheel Electric Forklift
• Condition: New
• Rated Lifting Capacity: 800 kg
• Maximum Lifting Height: 2,000 mm
• Support Configuration: Three-Wheel / Three-Point
• Power Source: Rechargeable Electric Battery
• Electrical System: 48V
• Battery Type: Dry Battery
• Battery Capacity: 52Ah
• Battery Configuration: Four Battery Units
• Travel Motor: Brushless AC Motor
• Travel Motor Power: 1,500W
• Controller: 24-Tube 48V/60V Universal Controller
• Steering System: Mechanical Steering
• Battery-Level Display: Included
• Charging Time: 6–8 Hours
• Working Time: 4–6 Hours
• Maximum Listed Gradeability: 12°
• Overall Length Without Forks: 1,600 mm
• Overall Length With Forks: 2,520 mm
• Overall Width: 900 mm
• Overall Height: 1,700 mm
• Machine Weight: 850 kg
• Body Construction: Thickened One-Piece Stamped Steel
• Colour: Customizable
• Suitable Surfaces: Indoor Industrial Flooring and Smooth Outdoor Surfaces

800kg Lifting Capacity

The forklift provides an 800 kg rated lifting capacity, making it suitable for everyday light-duty pallet and material-handling operations.

It can be used for:

• Palletized goods
• Warehouse inventory
• Boxes and packaged stock
• Workshop materials
• Manufacturing components
• Retail inventory
• Food and beverage stock
• Light industrial supplies

2,000mm Lift Height

The lifting system provides a maximum lifting height of 2,000 mm, supporting pallet lifting, stock positioning, loading, and low-level warehouse stacking.

The compact mast configuration is particularly useful in facilities where manoeuvrability and overall machine dimensions are important.

1,500W Brushless AC Motor

The electric drivetrain uses a 1,500W brushless AC travel motor for light-duty warehouse transport and positioning.

The brushless electric drive system supports:

• Smooth low-speed operation
• Quiet indoor performance
• Controlled warehouse movement
• Reduced motor maintenance
• No direct exhaust emissions during operation
• Convenient start-and-stop operation

48V 52Ah Battery System

The forklift operates on a 48V 52Ah rechargeable dry-battery system.

The battery configuration provides:

• Working Time: 4–6 Hours
• Charging Time: 6–8 Hours
• Battery-Level Display: Included

The integrated battery display allows the operator to monitor available battery power during operation.

Compact Three-Wheel Design

The three-wheel configuration is designed to improve manoeuvrability in confined commercial and industrial spaces.

With an overall width of only 900 mm, the forklift is suited to:

• Narrow warehouse areas
• Retail stockrooms
• Small workshops
• Compact production facilities
• Indoor loading areas
• Storage facilities
• Light manufacturing environments

Mechanical Steering

The mechanical steering system provides a straightforward steering arrangement suited to the forklift's compact light-duty design.

Combined with the three-wheel configuration, it supports controlled positioning during pallet movement and warehouse handling.

Heavy-Duty Steel Body

The forklift uses a thickened one-piece stamped steel body designed to provide structural support and protection for internal components.

The compact industrial chassis combines:

• Durable steel construction
• Stable three-point support
• Protected electrical components
• Compact overall dimensions
• Practical access for routine maintenance

Dimensions & Weight

• Length Without Forks: 1,600 mm
• Length With Forks: 2,520 mm
• Width: 900 mm
• Height: 1,700 mm
• Machine Weight: 850 kg

The compact dimensions make the forklift suitable for facilities where larger counterbalance forklifts have limited manoeuvring space.

12° Gradeability

The forklift has a listed maximum gradeability of 12°, supporting movement across suitable ramps and inclined working surfaces within the machine's operating limits.

Suitable Applications

This 800 kg electric forklift is suitable for:

• Warehouses
• Retail stockrooms
• Workshops
• Small manufacturing plants
• Logistics facilities
• Food and beverage storage
• Machinery-repair facilities
• Light industrial operations
• Indoor loading areas
• Distribution facilities
• Commercial storage
• Smooth paved work areas

Customization Options

Available customization includes:

• Battery configuration
• Battery capacity
• Charger configuration
• Lift height
• Fork dimensions
• Tyres
• Body colour
• Company logo
• Warning lights
• Horn
• Control panel

Safety Information

Only trained and authorized operators should use the forklift. Never exceed the 800 kg rated lifting capacity stated on the machine data plate.

Keep loads lowered while travelling and avoid sudden turns, unstable surfaces, and slopes beyond the specified operating limit. Inspect the forks, mast, battery, steering, brakes, tyres, controls, and warning equipment before each shift.
