The YG 5M Portable Mobile Lighting Tower is a high-output temporary lighting system designed for construction sites, road maintenance, mining operations, emergency response, warehouses, outdoor events, industrial maintenance and remote work locations.

Equipped with four 1,000W lighting heads, the tower provides approximately 4,000W total lighting power with broad 360° overall lighting coverage. A telescopic mast extends from approximately 1.7 metres to 4.8 metres, elevating the lighting heads for improved illumination across large work areas.

The portable hand-push mobile base allows convenient positioning around job sites, while the lighting system supports LED and halogen lamp configurations with an AC 110–240V, 50Hz electrical supply. A 5000K daylight lighting option provides bright white illumination for professional work environments.

Key Features

• 4 × 1000W Lighting Heads – Four high-output lamps provide approximately 4,000W of total lighting power.
• Up to 4.8m Telescopic Mast – Elevates the lighting system for improved wide-area coverage.
• 1.7m–4.8m Adjustable Height – Telescopic design provides flexible lighting height.
• 360° Overall Lighting Coverage – Four-head configuration distributes illumination around the work area.
• LED & Halogen Lighting Options – Supports professional lighting configurations for different applications.
• 5000K Daylight Lighting – Bright daylight-style illumination for construction and industrial work.
• AC 110–240V Input – Broad AC voltage compatibility for professional electrical installations.
• 50Hz Frequency – Designed for 50Hz electrical systems.
• Hand-Push Mobile Base – Allows convenient short-distance movement and positioning around job sites.
• 25L Fuel Tank – Generator-equipped configuration incorporates a 25-litre fuel tank.
• IP67 Protection – Provides environmental protection for demanding work conditions.
• -20°C to 45°C Operating Temperature – Suitable for operation across a broad temperature range.
• Customizable Configuration – Supports project-specific lighting, mast and power configurations.
• One-Year Warranty – Includes a one-year product warranty.

Product Specifications

Brand: YG
Model: 5M
Product Type: Portable Mobile Lighting Tower
Lamp Quantity: 4
Lamp Power: 4 × 1,000W
Total Lighting Power: 4,000W
Light Source Options: LED / Halogen
LED Luminous Efficiency: 110 lm/W
Lighting Coverage: 360° Overall Coverage
Colour Temperature: 5000K Daylight
Emitting Colours: White / Yellow
Input Voltage: AC 110–240V
Frequency: 50Hz
Power Supply: AC
Mast Type: Telescopic
Minimum Mast Height: 1.7m
Maximum Mast Height: 4.8m
Height Classification: 5m
Mobility: Hand Push
Fuel Tank Capacity: 25L
Dimming: No
Protection Rating: IP67
Operating Temperature: -20°C to 45°C
Lamp Life: 10,000 Hours
Customization: Supported
Warranty: One Year

4 × 1000W Lighting System

The YG 5M Mobile Lighting Tower is equipped with four lighting heads rated at 1,000W each, providing a combined lighting load of approximately 4,000W.

The four-head design provides powerful illumination for large temporary work areas where visibility is essential during night-time operations.

The system is ideal for construction, roadworks, mining, emergency operations and industrial maintenance.

1.7m–4.8m Telescopic Mast

The tower features a telescopic mast adjustable from approximately 1.7 metres to 4.8 metres. The product's 5M classification represents the rounded maximum mast-height category.

Raising the lighting heads improves illumination across larger work areas and helps provide elevated lighting around machinery, vehicles and equipment.

360° Wide-Area Lighting

The four-head lighting system provides approximately 360° total lighting coverage, allowing illumination to be distributed around the tower.

This wide-area lighting configuration makes the tower suitable for central positioning within construction zones, maintenance areas, industrial yards and temporary job sites.

LED Lighting

The LED configuration provides a listed luminous efficiency of approximately 110 lm/W, combining high-output lighting with efficient electrical performance.

LED technology provides fast startup, efficient energy use and reduced routine lamp maintenance for professional temporary lighting applications.

Halogen Lighting

The YG 5M lighting tower also supports a halogen lighting configuration.

Halogen lighting provides instant startup and warm illumination, making it suitable for temporary work-site applications requiring straightforward high-output lighting.

5000K Daylight Illumination

The lighting tower offers a 5000K daylight colour temperature, producing bright white illumination suitable for professional work environments.

5000K lighting provides excellent visibility for:

• Construction work
• Road maintenance
• Equipment operation
• Industrial maintenance
• Warehouses
• Emergency operations
• Outdoor work areas

AC 110–240V Power

The YG 5M Mobile Lighting Tower supports an AC 110–240V electrical input at 50Hz, providing broad voltage compatibility for professional electrical installations.

The wide input-voltage range supports use across different electrical environments and temporary power installations.

Hand-Push Mobile Design

The lighting tower uses a hand-push mobile base, allowing convenient movement and positioning around work sites without requiring a towing vehicle for short-distance relocation.

This mobile configuration is useful for construction sites, warehouses, industrial facilities and other locations where lighting needs to be repositioned during a project.

25L Fuel Tank

The generator-equipped lighting configuration features a 25-litre fuel tank, providing an integrated fuel supply for generator-powered lighting operation.

Generator power provides an independent lighting solution for remote locations without convenient access to mains electricity.

IP67 Protection

The lighting system carries a listed IP67 protection rating, providing dust-tight protection and resistance to temporary water immersion under defined conditions.

This protection supports use in demanding construction, industrial and outdoor environments.

-20°C to 45°C Operating Temperature

The YG 5M lighting tower has an operating temperature range of approximately -20°C to 45°C, supporting operation across a wide range of outdoor and industrial environments.

Suitable Applications

The YG 5M Portable Mobile Lighting Tower is designed for:

• Construction sites
• Road construction and repairs
• Mining and quarry operations
• Emergency response
• Disaster-relief operations
• Outdoor events
• Ports and warehouses
• Industrial maintenance
• Utility work
• Railway projects
• Temporary parking areas
• Remote job sites

Customization Options

The YG 5M Mobile Lighting Tower supports customization of:

• LED or halogen lighting
• Lamp wattage
• Lighting output
• Beam angle
• Colour temperature
• Mast height
• Mast lifting system
• Generator capacity
• Fuel-tank size
• Input voltage
• Cable length
• Wheel and chassis design
• Housing colour
• Branding

Safety Information

Position the lighting tower on firm, level ground and deploy all stabilizers before extending the telescopic mast. Never move the tower while the mast is raised.

Maintain safe clearance from overhead electrical lines, cranes, buildings, trees and other obstructions.

Electrical connections, lamp replacement, generator servicing, mast maintenance and cable repairs should be performed by qualified personnel. Generator-powered units must be operated in properly ventilated outdoor areas.
