Improve pallet stacking, warehouse transport, stock movement, and industrial material handling with this 2-Ton Electric Stacker Forklift. Designed for commercial material-handling operations, this electric stacker combines a 2,000 kg lifting capacity, AC travel motor, DC hydraulic pump motor, 1,070 mm forks, and selectable lift heights from 3,000 mm to 6,000 mm.

The fully electric system delivers quiet operation with no direct exhaust emissions at the point of use, making the stacker suitable for warehouses, factories, workshops, retail storage facilities, and logistics operations.

Key Features

• 2,000 kg rated lifting capacity
• Electric stacker forklift
• 3,000–6,000 mm lift-height options
• AC electric travel motor
• DC hydraulic pump motor
• 1,070 mm standard fork length
• Multiple fork-width options
• Rechargeable electric power system
• Quiet electric operation
• No direct exhaust emissions during operation
• Suitable for pallet stacking and transport
• Custom mast configurations
• Custom fork configurations
• Custom body colour and specifications
• Online technical support

Product Specifications

• Model: QRZ20260307
• Product Type: Electric Stacker Forklift
• Condition: New
• Rated Lifting Capacity: 2,000 kg
• Power Source: Rechargeable Electric Battery
• Travel Motor: AC Motor
• Hydraulic Pump Motor: DC Motor
• Lift Height Options: 3,000–6,000 mm
• Fork Length: 1,070 mm
• Fork Width Options: 75 / 93 / 100 / 125 / 150 / 175 / 200 mm
• Available Capacity Options: 1,000–5,000 kg
• Maximum Listed Equipment Range: Up to 7 Tons
• Colour: Customizable
• After-Sales Support: Online Technical Support
• Suitable Surfaces: Indoor Industrial Floors and Outdoor Paved Surfaces

2,000 kg Lifting Capacity

The 2-ton configuration provides a 2,000 kg rated lifting capacity, making it suitable for palletized goods, warehouse inventory, packaged materials, production supplies, and general industrial loads.

The stacker can support:

• Pallet lifting
• Warehouse stacking
• Rack loading
• Stock movement
• Production-line supply
• Truck loading support
• Material transfer
• Storage operations

3,000–6,000 mm Lift Height

Multiple mast configurations provide lift heights ranging from 3,000 mm to 6,000 mm, allowing the machine to accommodate different warehouse racking and stacking requirements.

Available lift-height configurations include:

• 3,000 mm
• 3,500 mm
• 4,000 mm
• 4,500 mm
• 5,000 mm
• 5,500 mm
• 6,000 mm

The selected mast configuration determines the final lowered mast height, overall raised height, free lift, and residual capacity.

Electric Drive System

The stacker combines an AC travel motor with a DC hydraulic pump motor.

This electric system supports:

• Smooth warehouse travel
• Controlled low-speed manoeuvring
• Electric pallet transportation
• Hydraulic lifting
• Controlled load positioning
• Reduced operating noise
• No direct exhaust emissions during operation

Hydraulic Lifting System

The DC-powered hydraulic system operates the mast and forks for pallet lifting and stacking.

The hydraulic lifting system is designed for:

• Smooth load lifting
• Controlled lowering
• Pallet positioning
• Warehouse rack stacking
• Loading operations
• Repetitive industrial handling

Fork Configuration

The standard fork length is 1,070 mm, providing compatibility with common pallet-handling applications.

Available fork-width configurations include:

• 75 mm
• 93 mm
• 100 mm
• 125 mm
• 150 mm
• 175 mm
• 200 mm

Fork configuration can be selected according to the pallet dimensions and material-handling application.

Electric Operation

Battery-powered operation makes this stacker particularly practical for indoor commercial and industrial environments.

Electric operation provides:

• Low operating noise
• No direct exhaust emissions
• Rechargeable power
• Smooth acceleration
• Precise low-speed movement
• Reduced engine-related maintenance
• Convenient indoor material handling

Available Capacity Options

Additional configurations are available for different material-handling requirements, including:

• 1,000 kg
• 1,500 kg
• 2,000 kg
• 2,500 kg
• 3,000 kg
• 3,500 kg
• 4,000 kg
• 5,000 kg

Higher-capacity configurations are also available within the equipment range.

Suitable Applications

This electric stacker forklift is suitable for:

• Warehouses
• Logistics centres
• Manufacturing plants
• Retail stockrooms
• Distribution facilities
• Food and beverage storage
• Garment facilities
• Building-material stores
• Machinery workshops
• Hotels
• Printing facilities
• Agricultural storage
• Production facilities
• Indoor logistics operations
• Paved loading areas

Customization Options

Available configurations include:

• Rated lifting capacity
• Lift height
• Mast configuration
• Fork length
• Fork width
• Battery configuration
• Charger configuration
• Operating controls
• Tyre configuration
• Operator platform
• Safety lighting
• Warning alarms
• Body colour
• Company logo

Delivery & Commissioning

Professional unloading and commissioning are recommended before operation.

Initial inspection should include:

• Battery and charger
• Fork alignment
• Mast assembly
• Lift chains
• Hydraulic system
• Drive system
• Steering controls
• Braking system
• Wheels and tyres
• Emergency-stop system
• Warning devices
• Capacity plate

Safety Information

Only trained and authorized personnel should operate the electric stacker forklift. Never exceed the 2,000 kg rated lifting capacity shown on the machine data plate.

Keep loads lowered during travel and operate on stable, suitable surfaces. Inspect the forks, mast, lift chains, hydraulics, battery, wheels, brakes, controls, and warning equipment before each shift.
